Part 7274-2-3

Cross references

Supplier data links this part number to: MS265743

Description

Approvals and Conformities NSN 5925-00-969-7783 MIL-SPEC# MIL-C-5809 Pilatus PN/Spec# 972.55.18.515 Alternate PN#s MS26574-3 Product Attributes Country of Origin United States Size 3 AMP Shipping Weight 0.05 pounds ECCN 9A991.d Color Family White Manufacturer P/N 7274-2-3 Schedule B Code 8536.20.0040 Pack Quantity 1 Ship Dimensions 3 x 3 x 1 inches Color White Klixon 7274-2-3 Circuit Breaker - 3 AMP Approvals/References/Specification Elettonica GmbH Part Number: 605-101-303 Honeywell International Part Number: 2068087-0702 Northrup Grumman Part Number: 11-13540-012 Raytheon Part Number: 419073-6 Pilatus Aircraft Part Number: 972.55.18.515 SAE Specification: AS26574 SAE Specification: AS58091 US Military Specification: MS26574-3 Body Style: Single Pole Type Bushing Length: 0.359 Inches Nominal Body Length: 0.780 Inches Maximum Body Width: 0.580 Inches Maximum Case Material: Metal Center To Center Distance Between Terminals Parallel To Length: 0.593 Inches Nominal Mounting Surface To Terminal End Distance: 1.420 Inches Maximum Pole Quantity: 1 Mounting Facility Type And Quantity: 1 Threaded Bushing Thread Quantity Per Inch: 32 Maximum Continuous Load Current Rating Per Pole: 3.0 Amperes Ac Single Location And 3.0 Amperes Dc Single Location Operating Voltage Type And Rating Per Pole In Volts: 115.0 Ac Single Location And 28.0 Dc Single Location Maximum Interrupting Capacity Current Type And Rating Per Pole In Amps: 10

Price spread · 4 priced listings

Each dot is one listing (hover for supplier & condition); color = condition.

Price by condition · median
