Part M22759/32-22-9
2 listings from 2 suppliers (CostAero, SkyGeek) · $0.10 – $12.00. Prices refresh weekly.
Description
SAE AS22759 wire is a fluoropolymer insulated, single-conductor wire offering excellent performance for a variety of military aerospace and commercial applications. It has high performance and reliability in severe wind and moisture prone (SWAMP) zones such as engine nacelles as well as areas requiring overload stability, low smoke emission and fire resistance, such as aircraft cabins. SAE AS22759/32 wire is designed for aerospace and military purposes. This wire features a tin-plated copper connector with a lightweight, cross-linked modified ETFE insulation layer. Features This M22759/32 tefzel hook-up wire features a 22 AWG, tin-plated copper conductor rated for 150°C and 600V, and features a cross-linked modified ETFE insulation. Color white. 600 volt rating 150°C temperature rating Excellent thermal stability High reliability High break strength and flex life High abrasion resistance Specifications Gauge: 22 AWG Conductor Material: tin-plated copper Insulation material: 150°C, fluoropolymer, cross-linked modified ETFE single insulation, lightweight Stranding: 19/34 Conductor Size: 0.029 mm Diameter: 0.041 – 0.045 in (1.04 – 1.14 mm) Weight: 2.8 lb/1000 ft Resistance (@ 20°C): 16.2 Ω/1000 ft
Price spread · 2 priced listings
Each dot is one listing (hover for supplier & condition); color = condition.
CostAero
SkyGeek
