Part M85049-95-24B-A
1 listing from 1 supplier (SkyGeek) · $17.79. Prices refresh weekly.
Description
Approvals and Conformities NSN 5935-01-251-5098 Product Attributes Country of Origin United States Shipping Weight 0.001 pounds ECCN EAR99 Manufacturer P/N M85049/95-24B-A Schedule B Code 8548.90.0100 Pack Quantity 1 Series M85049/95 Material Crescent Steel/Aluminum Thread Class: 3B Thread Direction: Right-Hand Overall Length: 1.785 Inches Nominal Center To Center Distance Between Mounting Facilities Parallel To Length: 1.375 Inches Nominal Center To Center Distance Between Mounting Facilities Parallel To Width: 1.375 Inches Nominal Overall Height: 0.123 Inches Minimum And 0.183 Inches Maximum Overall Width: 1.785 Inches Nominal Size Designation: 18 Mounting Facility Type And Quantity: 4 Clinch Nut Thread Quantity Per Inch: 32 Nominal Thread Size: 0.138 Inches Criticality Code Justification: Feat Special Features: Right Side Cut Away 1.001 In. Min And 1.031 In. Max Material: Aluminum Alloy Surface Treatment: Chromate Iii Style Designator: Square Shape Test Data Document: 81349-Mil-C-85528 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Typedata On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.). Thread Series Designator: Unc Specification/Standard Data: 81349-Mil-C-85528/2 Gov
