Part MS20220-3

Price trend · weekly low by condition

Description

Approvals and Conformities Product Attributes Country of Origin United States Shipping Weight 0.05 pounds ECCN 9A991.d Color Family Brown Manufacturer P/N MS20220-3 Schedule B Code 8487.90.0080 Pack Quantity 1 Series MS20220 Cable Size 1/8", 5/32", 3/16" Outside Dia. 4.250" Groove Dia. 3.750" Hub Dia. 0.455" Color Brown Material Phenolic Groove Depth: 0.250 Inches Nominal Groove Width: 0.275 Inches Nominal Outside Diameter: 4.255 Inches Nominal Overall Length: 0.625 Inches Nominal Bore Diameter: 0.3145 Inches Nominal Bore Length: 0.625 Inches Nominal Groove Radius: 0.097 Inches Nominal Material And Location: Fabric Overall Face Width: 0.422 Inches Nominal Design Form: Plain Bore Type: Straight Bearings: Included Groove Quantity: 1 Counterbore Feature: Not Included Bearing Quantity: 1 Keying Facility: Not Included Split Hub Feature: Not Included Lightening Hole: Not Included Integral Cooling Vane: Not Included Groove Shape: U Bore Feature: Included Bearing Type: Ball Hub End Outside Diameter And Location: 0.515 Inches Nominal Both Ends Distance From Outside Flange/Rim To Hub End And Location: 0.101 Inches Nominal Both Ends Special Features: If Requisition Is Not For Fms, Overseas Shipments, Naval Vessels, Priority Codes 1,2, Or 3, Or Individual Requisitions Over 25000 Dollars, Then Direct Vendor Delivery Nsn 3020-01-391-0853 Is Available At 15.7% Discount. Style Designator: Plain

Price spread · 3 priced listings

Each dot is one listing (hover for supplier & condition); color = condition.

Price by condition · median
