Part VS-50M
2 listings from 2 suppliers (CostAero, SkyGeek) · $593.38 – $614.15. Prices refresh weekly.
Description
The VLS-50M is a solid state electronically regulated power supply with fold-back current limiting to protect the power supply from excessive current or shorted output. Chassis mounted fuse and less than 5mV ripple peak to peak (full load and low line).This VLS-50M power supply (EDMO# VS-50M) has a variable 10A — 37A continuous power. Features Solid state electronically regulated Fold back current limiting protects power supply from excessive current and continuous shorted output Crowbar over voltage protection on all models Maintain regulation and low ripple at low line input voltage Three-conductor power cord Heavy duty heat sink 22 VDC — 32 VDC Externally Adjustable Voltage RIPPLE: LESS THAN 5MV PEAK TO PEAK (full load and low line) LOAD REGULATION: 0.08% from 0 to Full Continuous Load 77% efficiency rating Specifications Dimensions: 6 x 13-3/4 x 11 in Weight : 46 lb Continuous Duty: @13.8 VDC: 37 amps @10.0 VDC: 22 amps @05.0 VDC: 10 amps ICS*: @13.8 VDC: 50 amps @10.0 VDC: 24 amps @05.0 VDC: 11 amps Fuse: GMC 10A Power Terminals: 1/4″-20 Screw Type AC Current Draw: Idle: 324 mA Full Load: 8.17A Fan Cooled: No
