Part CI-101
Piper · 5 listings from 4 suppliers (CostAero, SkyGeek, Texas Air Salvage, Yingling Aviation) · $55.00 – $155.23. Prices refresh weekly.
Cross references
Supplier data links this part number to: 63019
Description
The CI 101 is a top loaded stub, monopole, transponder antenna with a mechanically captivated radiator machined from solid brass for impact resistance. Contact power is made from beryllium copper, and metallic parts are plated with bright nickel for corrosion protection. The CI-101 mounts through a single 0.6-inch diameter hole. FAA TSO authorized Frequencies covered: 1030-1090 MHz Weight: 0.06 lb Height: 3.33 in Frequency: 1030 MHz to 1090 MHz VSWR: 1.5:1 with return loss 14 dB Polarization: Vertical Radiation pattern: Equivalent to 1/4 inch wave stub Impedance: 50Ω Resistance DC: Open circuit RF power: 1 Kw Finish: Tin-nickel alloy Altitude: 30,000 ft FAA TSO: C74c RTCA Env.: DO-1387
Price spread · 4 priced listings
Each dot is one listing (hover for supplier & condition); color = condition.
Price by condition · median
Texas Air Salvage
CostAero
SkyGeek
CostAero
