KOSH Wittman Regional Airport

Oshkosh, WI · 2 miles S of OSHKOSH, WI

Public Towered Publicly-owned ICAO KOSH

Location & operations

Elevation: 808.5 ft
Coordinates: 43-59-03.7350N 088-33-25.3530W
Lat / Long: 43.9843708, -88.5570425
Mag. variation: 03W (2015)
Time zone: UTC -5 (UTC -6 during Standard Time)
Activated: 10/1937
ARTCC: CHICAGO CENTER
FSS: GREEN BAY FLIGHT SERVICE STATION
NOTAMs facility: OSH (NOTAM-D service available)
Attendance: MON-FRI 0700-1900, ALL SAT-SUN 0800-1700
Wind indicator: lighted
Segmented circle: no
Beacon: white-green (lighted land airport) Operates sunset to sunrise.
Lights: WHEN ATCT CLSD, ACTVT MALSR RWY 36; REIL RWY 18 & 27; HIRL RWY 09/27 & 18/36 - CTAF. HIRL 18/36 PRESET ON LOW INTST SS-SR, TO INCR INTST & ACTVT - CTAF. PAPI RWY 09, 27, 18 & 36 OPR CONSLY.

To (optional)

Longest 8,002 ft

Tap a runway to see its details.

Heading: 184 magnetic, 181 true
VGSI / PAPI: 4-light PAPI on left (3.00 degrees glide path)
Instrument approach: ILS
Approach lights: MALSR: 1,400 foot medium intensity approach lighting system with runway alignment indicator lights
Markings: precision, in good condition
Touchdown point: yes, no lights
REIL: yes
Traffic pattern: left
Threshold elevation: 789.6 ft.
Obstructions: 15 ft. ant, 550 ft. from runway, 250 ft. left of centerline, 23:1 slope to clear

Heading: 004 magnetic, 001 true
VGSI / PAPI: 4-light PAPI on left (3.00 degrees glide path)
Markings: precision, in good condition
Touchdown point: yes, no lights
REIL: no
Traffic pattern: left
Threshold elevation: 808.4 ft.
Obstructions: 61 ft. trees, 3000 ft. from runway, 185 ft. left of centerline, 45:1 slope to clear

Heading: 274 magnetic, 271 true
VGSI / PAPI: 4-light PAPI on left (3.00 degrees glide path)
Declared distances: TORA:6179 TODA:6179 ASDA:6179 LDA:5648
Markings: nonprecision, in good condition
Displaced threshold: 531 ft.
Touchdown point: yes, no lights
REIL: yes
Traffic pattern: left
Threshold elevation: 775.8 ft.
Obstructions: 37 ft. tree, 720 ft. from runway, 150 ft. right of centerline, 14:1 slope to clear

Dimensions: 3424 x 75 ft. / 1044 x 23 m
Surface: asphalt, in fair condition
Weight bearing: Single wheel MAXIMUM WEIGHT BEARING CAPACITY FOR ANY ACFT IS 50000 LBS.

Heading: 228 magnetic, 225 true
Markings: basic, in fair condition
Touchdown point: yes, no lights
REIL: no
Traffic pattern: left
Threshold elevation: 775.2 ft.
Obstructions: 21 ft. rr, 500 ft. from runway, 155 ft. left of centerline, 14:1 slope to clear

Dimensions: 3061 x 75 ft. / 933 x 23 m
Surface: asphalt, in fair condition
Weight bearing: Single wheel MAXIMUM WEIGHT BEARING CAPACITY FOR ANY ACFT IS 50000 LBS.

Heading: 312 magnetic, 309 true
Markings: basic, in fair condition
Touchdown point: yes, no lights
REIL: no
Traffic pattern: left
Threshold elevation: 781.2 ft.
Obstructions: 15 ft. road, 217 ft. from runway, 127 ft. right of centerline, 1:1 slope to clear

None published.

Procedure charts published by the FAA (public domain). Confirm the current cycle before flight.

Control Tower: yes
Ctaf: 118.5
Unicom: 122.95
Atis: 125.9
Wx Asos: PHONE 920-426-1644
Oshkosh Ground: 132.3 [16 MAR-31 OCT 0600-2200, 1 NOV-15 MAR 0600-2100]
Oshkosh Tower: 118.5 290.9 [16 MAR-31 OCT 0600-2200, 1 NOV-15 MAR 0600-2100]
Milwaukee Approach: 127.0
Milwaukee Departure: 127.0

Fuel: 100LL JET-A+ A+:A+ AND 100LL AVBL FOR FEE AFTER HRS, 920-236-7827.
Fuel available: 100LL JET-A+ A+:A+ AND 100LL AVBL FOR FEE AFTER HRS, 920-236-7827.
Parking: hangars and tiedowns
Airframe service: MAJOR
Powerplant service: MAJOR
Bottled oxygen: NONE
Bulk oxygen: HIGH/LOW
